R＆B顶级开发尖端技术CAMD（计算机辅助模具设计开发）解决方案，让工程师能够生成完整的利用3D计算机生成的3D模具设计。

R&B SplitWorks 2017 SP0.1 | 55.1 mbR&B has released an update to SplitWorks 2017 is a revolutionary new product, using advanced technology, to automate the process of core and cavity separation and creation for the plastic molding, blow molding, sheet metal (progressive dies, bending), aluminum injecting, investment casting, wax molding for ceramics technology.

SplitWorks 2017 SP0.1 - release notes:- SplitWorks 2017 SP0.

1 runs under SOLIDWORKS 2019 SP0.

0.

SplitWorks 2017 SP0 - release notes:New Functionality– Create Sub Inserts is used to create sub inserts with/without a base from an insert (part) in an assembly given a sketch or a set of faces defined by selection or by a color.

For a sketch it must be created on the base of the insert or on a plane (at the part level) and containing one or more closed loops prior to activation of the menu.

For a set of face either select the faces on the fly or prepare a group of faces with the same color.

The sub inserts are created as separate parts, added to the assembly and subtracted from the insert.

It is available through the Tools > SplitWorks >Create Sub Inserts… menu system, the icon menu (if activated in the assembly document) or the CommandManager tab.

ModificationsLoft- Added circular planar surface to the planar surface options.

When planar option is identified then only the Distance parameter is displayed which indicates the extra margin for the planar surface.

Add Planar Surface- Icon has been added to the Chain Edges dialogue to allow quick access to this menu.

– Chain Edges has been optimized to offer the correct solution automatically (with no need in most cases to change the direction).

– Update Surface automatically rolls up the tree to the relevant (core or cavity) surface and rolls back down after performing the update.

This may lead to errors due to changes in the original surface which will have to be corrected.

– Create Side Core direction can be defined by a circle as well.

– Right Hand Mouse button SplitWorks menus (Chain Edges, Planar Surface and SplitWorks Delete) are now on the main menu and not under a sub-menu.

Corrections– User Blanks can now be defined in all versions.

Previously the user blank had to be defined in version SOLIDWORKS 2014 or before.

Product:R&B SplitWorksVersion:2017 SP0.1Supported Architectures:x64Language:english, french, german, italian, portuguese, spanish, polish, turkishSystem Requirements:PCSupported Operating Systems:Windows 7 or 10Software Prerequisites:DS SolidWorks 2015-2019Size:55.1 mb
