HEXPRESS™/Hybrid可自动生成任意复杂三维几何体的全六面体非结构网格。

可直接输入多种作图软件的数据，并对其有自动修补动能。

是NUMECA公司专门针对异常复杂模型开发的快速、高效网格生成器。

采用全球先进的并行网格生成技术，通过八叉树的网格划分方法生成包含六面体（主要）和四面体的混合网格，并自动生成高质量的边界层网格，其集成的自动包装技术和洞搜索技术可有效避免大量的CAD清理和修补过程，从而实现复杂模型快速、高自动化、高质量的网格生成。

关键特性:针对任意复杂的几何模型生成高质量的混合网格：内流/外流，CFD和FEM网格根据用户需求进行全边吸附自动完成CAD模型的清理、补洞等修复狭小缝隙和重叠自动修补大的缝隙采用HoleSearcher进行检测和修补根据用户指定细化级别给出几何捕捉详尽信息先进的并行网格生成技术（SMP共享内存）图形用户界面全脚本化采用平滑过渡实现灵活的边界层插入体网格划分，纯四面体，纯六面体或其混合网格变形一步实现相似几何模型的网格划分可划分狭小细面（如进气道等）HEXPRESS™/Hybrid的特性适用于广泛的工业领域：汽车初期设计、外流场分析、热管理等计算火车、货车和汽车生产商工业、农业和建筑机械石油天然气工业集成旋转机械和飞行器行业环境模拟电子工业NUMECA HEXPRESS/Hybrid 8.1 | 3.1 GbNUMECA International is delighted to announce the official release of HEXPRESS and HEXPRESS/Hybrid 8.

1.

This applications produces unstructured hex-dominant conformal meshes of complex geometries, starting from unclean CAD data.

Thanks to the fact it can run on multiple processors it's ultra fast on top.

About NUMECA HEXPRESS/Hybrid.

HEXPRESS/Hybrid is the latest of NUMECA's meshing tools designed for meshing complex geometries starting from unclean CAD data.

The tool produces unstructured hex-dominant conformal meshes in parallel, including high quality viscous layers.

The integrated automatic wrapping technology and the HoleSearcher allow the user to avoid the time spent on CAD cleaning and repairing, thus significantly reducing the engineering time spent on the generation of a mesh.

- HEXPRESS generates non-conformal body-fitted full hexahedral unstructured meshes on complex arbitrary geometries.

In addition, the advanced smoothing capability provides high-quality boundary layers insertion.

HEXPRESS uses a volume-to-surface approach, suppressing the need for a surface mesh.

- HEXPRESS/Hybrid generates unstructured hex-dominant conformal meshes.

HEXPRESS and HEXPRESS/Hybrid use a similar volume-to-surface approach, suppressing the need for a surface mesh.

Both systems run in batch or interactive mode and are interfaced to all major commercial CFD codes.

This product is part of AutoMesh.

About Numeca International Inc.

NUMECA International SA develops computational fluid dynamics (CFD) software for the simulation, design, and optimization of fluid flow and heat transfer worldwide.

It offers automated and customized flow integrated environments (FINE), including FINE/Turbo for the simulation of rotating and turbomachinery flows; FINE/Open for the simulation of complex internal and external applications; and FINE/Marine for marine applications.

Product:NUMECA HEXPRESS/HybridVersion:8.1Supported Architectures:x64Language:englishSystem Requirements:PC / LinuxSupported Operating Systems:Windows 7even or newer / Fedora Core 22.x, 25.x, (K)Ubuntu 14.04, 16.04, CentOS 7.0.1406Size:3.1 Gb
