CG数据库 >> CST Studio Suite 2019 x64

计算机仿真技术公司(CST)欣然宣布2019年版其旗舰的电磁仿真软件CST STUDIO SUITE。

CST STUDIO SUITE 多年的研究和发展,包括在各个层面的改进和创新,从优化求解技术新的功能区为基础的GUI。

这些进步提升CST STUDIO套件的性能,易用性和多功能性,毫不妥协,并引导您轻松通过复杂的电磁系统。

CST STUDIO SUITE被广泛应用在通信和电子医疗保健和航空等领域工作的工程师,帮助他们电磁现象的建模和评估他们的设计,以获得最佳性能。

结合高频和低频模拟工具以及专门求解器的应用,如印刷电路板,电缆和带电粒子设备,可以应用到许多典型的工程任务,如EMC / EMI评估,SI和PI的分析,设计CST Studio套件优化,天线及滤波器的调谐。

CST Studio Suite 2019 | 3.3 GbComputer Simulation Technology (CST), part of SIMULIA, a Dassault Systèmes brand, announces the release of its flagship EM simulation software, CST Studio Suite 2019.

CST Studio Suite 2019 - What's new:CST Studio Suite 2019 builds on industry-leading simulation technology with a range of new features for the design, simulation and optimization of components and systems.

New features include encrypted data sharing, the next generation of Perfect Boundary Approximation (PBA), full integration of the voxel body model poser, and the hybrid solver for bidirectional hybrid coupling between all the general purpose high-frequency solvers.

The 2019 release is also available on the Dassault Systèmes 3DEXPERIENCE platform, allowing direct links to other design and simulation tools.

These tools increase the agility of CST Studio Suite for modeling and simulating complex systems, and allow electromagnetic simulation to be applied in large projects spanning multiple departments and suppliers.

About CST Studio Suite.

The electromagnetic (EM) simulation software CST STUDIO SUITE is used by industry-leaders to design, analyze and optimize components and systems across the EM spectrum.

The CST Complete Technology approach means that all solvers are available within a single graphical user interface, with strong links between different solvers.

The 2018 release of CST STUDIO SUITE develops on previous success with a range of new features for simulating entire systems with hybrid methods.

One key strength of CST STUDIO SUITE is the ability to link multiple simulations with different solvers into a single workflow with System Assembly and Modeling (SAM).

In 2018, the improved Assembly Modeler offers users a more efficient way to combine multiple components into a system employing a 3D environment optimized for complex models.

This is complemented by new features for EM/circuit co-simulation and the Hybrid Solver Task providing bidirectional solver coupling between the Time Domain and Integral Equation Solvers – a major step forward for hybrid simulation.

For bio-EM simulations, the voxel poser tool, previously a separate product, is now integrated directly into the CST STUDIO SUITE interface, offering users direct access to the voxel poser during the modeling process.

Body models using the tetrahedral mesh can now move realistically to simulate breathing, which is important in the design of medical devices.

Filter Designer 3D, CST’s tool for designing cross-coupled filters and calculating coupling matrices, is now connected directly to the powerful optimizers in CST STUDIO SUITE.

This means that the optimizers have access to the coupling matrix calculation, allowing faster and more intelligent filter tuning.

Photonic and terahertz applications are a growing trend, and CST STUDIO SUITE offers a new alternative interface for these areas, with direct access to optical features.

It also now allows simulations to be set up using wavelength rather than frequency.

CST STUDIO SUITE 2018 introduces the ability to calculate farfields on multilayer substrates, which is useful both for photonic applications and for simulating antennas printed on complex PCBs.

Behind the scenes, the core of the software is as ever fine-tuned to optimize performance on the latest hardware, and CST STUDIO SUITE is being introduced to the Dassault Systèmes 3DEXPERIENCE platform with links to other SIMULIA tools.

About Computer Simulation Technology.

CST offers accurate, efficient computational solutions for electromagnetic design and analysis.

Our 3D EM simulation software is user-friendly and enables you to choose the most appropriate method for the design and optimization of devices operating in a wide range of frequencies.

Product:CST Studio SuiteVersion:2019Supported Architectures:x64Language:englishSystem Requirements:PCSupported Operating Systems:Windows 7even or newer / Server 2008 (12) R2 or Server 2016Size:3.3 Gb


CST Studio Suite 2019 x64的图片1
CST Studio Suite 2019 x64的图片2
CST Studio Suite 2019 x64的图片3
CST Studio Suite 2019 x64的图片4
CST Studio Suite 2019 x64的图片5
CST Studio Suite 2019 x64的图片6
CST Studio Suite 2019 x64的图片7
CST Studio Suite 2019 x64的图片8
CST Studio Suite 2019 x64的图片9
CST Studio Suite 2019 x64的图片10
CST Studio Suite 2019 x64的图片11
CST Studio Suite 2019 x64的图片12
CST Studio Suite 2019 x64的图片13

发布日期: 2018-12-11
