CG数据库 >> 《西门子PLM产品解决方案6.0.5.3 MP12升级包》Siemens PLM NX 6.0.5.3 MP12 Update

UG (Unigraphics) NX是一套全视觉化电脑辅助设计/工程/製造系统,拥有虚拟整个製造厂商流程的科技技术。UGS藉由UG NX这一套囊括全產品工程的解决方案来全力协助製造业用户创造他们最佳的竞争优势,让用户能在数位化的协同环境下进行產品的建模与製造流程。实体/特徵/曲面模型建构模组 Part Modeling

UGS Unigraphics团队以27年优越的系统整合、技术发展与实战经验之累积,在高等数学Parasolid核心上,开发出一系列高效能產品,已成為领导业界之最佳选择。

‧实体模型模组(Solid Modeling)

‧特徵模型模组(Features Modeling)

‧自由曲面模型模组(Free-Form Modeling)

‧UG通道模组(Gateway)

组立设计模组 Product Modeling

UG组立模组之高效能及轻量化技术,早已在航太、汽车及各领域中,著有实际之例绩,為领导技术与系统整合之最佳选择。

‧组立设计模型模组(Assembly Modeling)

‧进阶组立设计模组(Advanced Assemblies)

设计出图模组 Product Modeling

单一资料库与双向关联性的系统架构,可对实体 / 曲面模型做自动排版功能。

‧排版出图模组(Drafting)

‧尺寸标示功能(Dimension)

外形塑造模组 Shape Studio

Shape Studio专业造型软体,能使工业设计的附加价值,表现在產品的外观美学上。

‧自由曲面3D塑型模组(UG/Freeform Shape 3D)

‧高画质静态画像模组(UG/Render)

‧塑型分析模组(UG/Analyze Shape)

‧动态影像模组(UG/Visualize)

模具设计精灵 Mold Wizard Design

MoldWizard模具设计精灵引入模具设计的经验与知识,并运用流程精灵之操作导引,整合软体运算技术与完整的模具资料库,提供最佳的模具设计环境。

固定轴向铣削加工模组 Cavity Mill/Fixed Contour

针对复合实体/高阶曲面之铣削加工,UG_CAM可整合其他软体之CAD档案,快速而精确地计算刀具路径,并直接產生GM Code/ Nurbs格式,配合各型高速加工母机,大幅提昇製造成效。

‧两轴半等高加工模组(Planar Mill)

‧3D曲面等高加工模组(Core & Cavity Mill)

‧固定轴向加工模组( Fixed Axis Milling)

‧多面体加工模组(Facet Machining)

‧自动清角加工模组(Flow Cut)

‧NURBS Path模组

多轴铣削加工模组 Multi Axis Milling

Multi Axis CAM能针对复杂曲面、倒勾复角、一体成型、特殊材质...等之精密加工件,做多轴铣削加工,以降低结构内应力,获致最佳机製品质。

‧多轴变异式加工(Veriable Contour)

‧多轴顺序式加工(Sequential Mill)

‧多轴变异式分层加工(VC Multi Depth)

‧多轴变异式沿边界范围倾角加工(VC Boundary ZZ Lead Lag)/

‧多轴变异式沿曲面区域倾角加工(VC Surf Reg ZZ Lead Lag)

‧高阶曲面等分加工(Zig Zag Surface)

‧使用者参数设定(Mill User)/ 控制器参数设定(Mill Control)

车床加工模组 Turning

UG Turning提供最多样化的车削方式、车削角度与走刀路径,為功能最齐全之车床系统。

‧车床走刀方式(Subtype)

‧车床机製参数(Cutting Parameters)

线切割加工模组 Wire EDM

针对直断面实体/规律曲面/复合曲线之线切割加工。

‧线割走刀方式(Subtype)

‧线割控制参数(Cutting Parameters)

‧速率控制(Feed Rates)

加工后处理模组 Post Processing

UG Post Processing后处理模组在多轴切削之数值演算上,支援二~五轴铣床、车床、线切割、钻床...等全系列之控制器,提供各型工具机最可靠的解决方案。

‧后处理调整器(Post Builder )

‧NC输出码执行程式(Post Exec)

‧进阶后处理动态程式馆(Post Adv. Kine. Lib.)

‧工单產出(Shop Doc)

刀具路径编辑及切削模拟 Toolpath Edit/ Verify

‧刀具路径编辑与图形模拟(Graphical Tool Path Editor)

‧电脑辅助虚拟加工模组(CAM Visualize)

Siemens PLM Software, a business unit of Siemens Industry Automation Division and a leading global provider of product lifecycle management (PLM) products and services, May 20, 2008 announced the release of NX 6 digital product development software that provides features driven from Siemens PLM Software’s recently announced synchronous technology.

“NX 6 delivers on the breakthrough in design productivity we announced last month,” said Joan Hirsch, vice president of NX product development, Siemens PLM Software. “We’ve integrated synchronous technology into the NX comprehensive toolset, delivering major enhancements to design, simulation and manufacturing. This release enhances our strong momentum and the market share growth NX is experiencing.”

"Our implementation of NX is realizing productivity improvements that have exceeded our targets and overall we’re seeing a 20 percent improvement in the CAD operation efficiency,” said Keigo Fukushi, general manager, Process Information Management Department, R&D Engineering Management Division, Nissan Motor Co., Ltd.

Four key NX 6 innovations

- Flexibility – NX 6 provides users new flexibility with Design Freedom powered by synchronous technology that leverages the ease of direct editing in the model creation process. Design Freedom now combines the best of constraint-driven techniques with direct modeling in a technology that provides users with up to a 100 times faster design experience than ever before.

- Strength – NX 6 handles extremely complex problems through comprehensive CAD/CAM/CAE. NX 6 advanced simulation handles the most demanding CAE challenges, providing a 30 percent reduction in physical prototypes.

- Coordination – the NX 6 unified process enables collaborative product development that leads to 20 percent faster cycle times through process efficiency improvements such as feature-based machining.

- Productivity – NX 6 provides engineers and designers greater productivity through major re-use enhancements such as scrapbook modeling that can improve cycle times by 40 percent. With NX 6 engineers gain greater productivity through their ability to leverage multi-CAD data within their design, analysis and manufacturing processes thereby reducing the need to re-master information for improved analysis and machining times.

About Siemens PLM Software

Siemens PLM Software, a business unit of the Siemens Industry Automation Division, is a leading global provider of product lifecycle management (PLM) software and services with 7 million licensed seats and more than 71,000 customers worldwide. Headquartered in Plano, Texas, Siemens PLM Software works collaboratively with companies, delivering open solutions to help them make smarter decisions that result in better products.

《西门子PLM产品解决方案6.0.5.3 MP12升级包》Siemens PLM NX 6.0.5.3 MP12 Update的图片1
《西门子PLM产品解决方案6.0.5.3 MP12升级包》Siemens PLM NX 6.0.5.3 MP12 Update的图片2

发布日期: 2013-2-13
