CG数据库 >> 《3DQuickPress5.2.1三维连续冲模设计解决方案32位破解版》3DQuickPress 5.2.1 32bit for SolidWorks 200

3DQuickPress是SolidWorks的附加元件级进模设计。随着零件的三维实体模型,三维条可以快速方便地创建,并传达整个工作进一步之前使用的模具没有时间详细的免费的SolidWorks ® eDrawings的观众群明确瓦特.

3DQUICKPRESS 3.1.10 FOR SOLIDWORKS

软件简介—SoftWare Description: 3DQUICKPRESS 3.1.10 FOR SOLIDWORKS 冲模插件

SolidWorks公司认证的黄金合作伙伴3DQuickPress是一套完全整合于 SolidWorks 的三维连续冲模设计解决方案。与 SolidWorks 统一界面,完全一致的使用风格。本系统包含零件分析及展开、料带布排、模架及冲头设计等功能,为电子,家电及汽车结构设计等行业提供从三维建模,零件展开,三维组装到二维出图的完整解决方案。

3DQuickPress唯一使用3D才能解决在2D作业中所无法预知的错误并透过协同设 计达到快速准确的冲模设计。3DQuickPress是SolidWorks对于冲模设计的解决方案软体。直接 透过3D模型。迅速完成连续冲模的设计,并透过eDrawing有效的 达到资料沟通,因而能在短期间完成冲模设计。 强大的钫金特微辨识处理技术可以快速依据SloidWorks钫金或外 部资料或所提供的资料库来计算出弹性与弯曲的误差,以及冲压 行程的调整与模具的自动产生。

冲模排列设计“Strip Layout Manager"提供直觉式的工具,经由 简单对话方式快速完成设计方案。

功能包括:

● 排列最佳话      ● 支援多零件  ● .模刻冲模设计

● 切割冲模冲头   ● 清角处理     ● 部份弯曲

● 插入/删除工步  ● 模具产生     ● .报告材料利率与切割力冲心点

Die Set Design 设计一开始就以完成料带设计的工作来进行,3DQuickPress将会自动产生所有定义在此料带上的冲头。

功能包括:

● 自动化冲头及镶块生成  ● 标准件与模具库

● 自动建立模版开口    ● 流程动画表现

● 零件表(BOM)     ● 创建模版开口及镶块的辅助草图工具专业提供CAD/CAM/CAE/CFD/GIS/EDA/AI/FEM软件

3DQuickPress 5.2.1 32bit for SolidWorks 2009-2012 32bit

3DQuickPress is a SolidWorks add-on for progressive die design. With a 3D solid model of the part, a 3D strip can be created quickly and easily, and also be communicated clearly throughout the work group using the free SolidWorks eDrawings viewer before further detailing of the die without time wasted.

About 3D QuickTools Ltd.

3D QuickTools Ltd. was set up by a group of experienced tooling specialists and CAD/CAM programmers in 2002. Our mission is to enable tooling engineers to use the power of 3D design. The flagship product - 3DQuickPress got the support and applause from SolidWorks Corporation and many famous tooling companies even before the initial product launch. The die design system is based on SolidWorks platform to take the benefits of its powerful modeling capabilities. The company concentrates to develop trade-specific functions to make 3DQuickPress the best-in-class solution to the metal manufacturing industries.

About 3DQuickPress

3DQuickPress was certified by SolidWorks Corporation as Certified Gold Product in June 2006. The company is one of the most active SolidWorks partners in the manufacturing design market. In 2005, 3D QuickTools Ltd. lined up with ESI Group, the French global leader in virtual prototyping. The co-developed product, 3DQuickForm, was launched in 2005. It became one of the most preferred stamping simulation software offering accurate blank prediction at affordable price. Today almost one third of the new customers purchase 3DQuickForm with 3DQuickPress to handle stamping of complex form.

3DQuickPress was introduced to the international market in 2003. There are reselling partners over 20 countries today. Most of them are specialized in technical support and consultancy in tooling business. 3DQuickPress users are mainly coming from automobile, aircraft, electronics, and medical industries located in USA, Canada, Germany, and Japan. The demand for 3DQuickPress from China and India market increases significantly in recent years too.

Name: 3DQuickPress

Version: 5.2.1 32bit

Creator: www.3dquicktools.com

Interface: english

OS: Windows XP / Vista / Seven

Platform: SolidWorks 2009-2012 32bit

Size: 587.6 mb

VIP高速地址:

《3DQuickPress5.2.1三维连续冲模设计解决方案32位破解版》3DQuickPress 5.2.1 32bit for SolidWorks 200的图片1
《3DQuickPress5.2.1三维连续冲模设计解决方案32位破解版》3DQuickPress 5.2.1 32bit for SolidWorks 200的图片2

发布日期: 2012-3-4
