3DVIA Composer是 3DVIA Composer 解决方案的核心产品。作为一种桌面应用程序，可用于直接从 3D 数字产品数据创建产品文档内容。3DVIA Composer 是为非 CAD 人员设计的，不需要 CAD 知识或培训。可以按现有公司标准创建爆炸视图，并加上标签和零件序号进行注解。此外，3DVIA Composer 允许创建样式和智能视图，后两者可应用于任何内容以确保视觉效果的一致性。
使用 3DVIA Composer 的内置技术图解功能可以轻松快捷地制作 2D 线条图。输出内容包括 3D 动画以及 JPEG、SVG、CGM 等高分辨率图像。
3DVIA Sync是一种自动化工具，该工具可关联 3DVIA Composer 生成的内容与 3DCAD 数据。元数据、几何图形或产品结构中的更改可以在 3DVIA Composer 生成的内容中自动进行更新，从而确保文档的准确性和一致性。
3DVIA Safe是一种加载项实用程序，用户可用来控制和管理对 3DVIA Composer 生成的内容知识产权的访问。有了 3DVIA Safe，内容创建者可以在用3DVIA Player 播放内容时管理访问控制，还可以使用专利技术“Secure 3D Brush”防止对知识产权的复制或盗用。
3DVIA Check是一种加载项实用程序，利用该实用程序，用户能确保各种操作步骤在现实中得以执行。3DVIA Check 提供动态和静态碰撞检测，允许用户快速检验维修和装配工艺。这样，可以确保操作员能够对装配体中的零部件进行维护或修理。3DVIA Player 是一种免费产品，文件接收者可利用它来查看 3DVIA Composer 生成的文档。3DVIA Player 的高性能与 3DVIA Composer 没有什么两样。3DVIA Player 决不只是一个简单的浏览器，文件接收者可用它来获得与产品文档高度互动的体验。此外，3DVIA Player 还能嵌入到 MS Office 应用程序、HTML 和 PDF 中。
DS 3DVIA Composer V6R2015 (x64) | 592 MB
Description: The product of the company Dassault Systemes, designed to create interactive tutorials, presentations and technical illustrations based on 3-dimensional model of the product. With support for a wide range of file formats, 3DVia Composer allows you to work with the product entirely, even if it was created in different CAD-systems. The results can be saved in native format 3DVia Composer automatically added along with a free viewer or exported to a common standard data formats such as PDF, HTML, AVI and SVG.
3DVia Composer - convenient and functional system design multimedia content, automating the process of creating instructions for assembly / disassembly, technical illustrations, interactive 3D animations, marketing materials, product catalogs, training materials, web-pages and much more.
amenities:
Easy, simple and intuitive user interface, and an open XML-based architecture solutions 3DVia Composer allows a wide range of users with no technical skills to develop technical documentation, create associative 2D and 3D materials based on design CAD-models of products.
Benefits:
3DVia Composer can be used successfully in sales, marketing, maintenance and overhaul (MRO), training, engineering and production departments, as well as to monitor and manage complex projects management company.
Effective use of information about the product:
3DVia Composer provides the creation of technical illustrations, video and interactive 3D material, which not only improve the perception of information through greater visibility, but also greatly improve the quality of the generated documentation. Using interactive graphic elements can significantly reduce the amount of text items, which reduces time and cost to translate a text document with the release of her multi-lingual.
compatibility:
3DVia Composer allows you to import data from most modern CAD and PLM systems directly in their own format or in standard neutral formats 3DXML / IGES / STEP. Imported objects are grouped in an assembly on the basis of which can be formed specification (BOM - Bill of Materials). Developed interactive documents can be stored in compact executable EXE-files (for example, the volume of the original CAD model, 50 MB, * .exe file 3DVia Composer - the result of converting this model into a format 3DVia Composer will have a capacity of only 2.5 Mb). These EXE-files already contain a built-in free 3DVia Player, so that they can be open to absolutely any computer without using any pre-installed specialized software (such as CAD-systems or proper 3DVia Composer). Projects 3DVia Composer can also be saved in various standard data formats such as: PDF, HTML, SVG, CGM, 3DXML, AVI, Microsoft Office and others that allows the use of graphics, multimedeynye, interactive objects 3DVia Composer in the traditional text documents for various purposes . Thus, 3DVia Composer significantly increases the efficiency of the process of creating documentation, eliminating the need for costly professional services (photographers, illustrators). Viewed software reduces the cost of documentation, and, consequently, the product as a whole, while improving the quality of presentation and perception of the material.
application:
Application 3DVia Composer allows you to reduce time spent on rework and update the documentation when you make changes in product design. Updates are performed automatically by the associative connection with the design CAD- model. Cost and terms of design documentation is also declining due to more effective use of information on future product. Development of documentation 3DVia Composer can begin at an early stage of design when the design model are not fully developed, and at later stages, upon completion of the design process, you can easily update the graphics and multimedia content in a prepared document template.
documents:
Interactive documents created in 3DVia Composer, can be protected from unauthorized dissemination and use by assigning access rights to the options for viewing, copying and printing, as well as full / partial display / hide individual items or under-managed quality / accuracy of the displayed 3D models, when the geometric parameters of the product is intellectual property.
The composition of the solutions 3DVia Composer:
3DVia Composer - base module that provides an interactive development of technical documentation on the basis of design CAD-models of products. 3DVia Composer is designed specifically for developers of technical documentation and does not require special skills and knowledge in the use of CAD / CAM / CAE-systems. Visual and intuitive user interface provides the convenience and high performance work with graphic and text objects, their properties and performance. All these parameters can be stored in a library of styles for reuse in new projects. Interactive animation (the processes of assembly / disassembly, maintenance and repair, the demonstration model of a product in different angles, annotations and explanatory graphics), high-quality vector images (SVG, CGM), and technical illustrations (callout types, specifications) can be created very easily and quickly.
3DVia Player - a free utility designed for viewing projects 3DVia Composer. This utility is built into interactive tutorials 3DVia Composer (EXE-files) that allows you to view these documents on any computer without special software. 3DVia Player provides the OLE-objects are embedded in the standard documents Microsoft Office, System PDM (such as ENOVIA SmarTeam) and web-page by.
3DVia Safe - This module is designed to control access rights to the online documentation created using 3DVia Composer (view, print, display items, the quality / accuracy of the model, etc.) and provides reliable protection of intellectual property of the company.
3DVia Sync and 3DVia Sync Integration - these modules provide the synchronization and automatic updates of the geometry, metadata and specifications when the original CAD-models of products.
3DVia Path Planning and 3DVia Check - these modules provide automated creation of a sequence of assembly / disassembly of assemblies and mechanisms to control stolknoveniypic
What's New:
Updates: official site does not provide any info about changes in this version
Year / Date of Release: 2014
Version: V6R2015 (build 6.14.0.2652)
Developer: Dassault Systemes
Bit depth: 64bit
Language: Multilingual (Russian present)
Medicine: Present (Team-SolidSQUAD)
System Requirements: OS Windows, Intel Pentium® 4, Intel® Core ™ 2 Duo, 2GB RAM, A graphics adapter with 3D OpenGL acceleration is required for optimal performance. NVIDIA® is highly recommended (NVIDIA Quadro® FX).
