CG数据库 >> Mentor Graphics Precision 2019.1

Mentor Graphics Precision 2019.1是一个综合平台,可最大限度地提高现有可编程逻辑器件(CPLD和FPGA)和下一代数百万门现场可编程片上系统(FPSoC)器件的性能。 Precision Synthesis工具以VHDL,Verilog和SystemVerilog条目,高级寄存器传输级逻辑综合,基于约束的优化,最先进的时序分析,原理图查看和封装的位置等形式提供设计捕获。

Precision RTL Plus是Mentor Graphics的旗舰FPGA综合解决方案,为商业应用以及军用和安全关键系统提供突破性优势。 Precision RTL Plus提供了一种改进的FPGA设计方法,可提高设计人员的工作效率。通过其先进的综合技术和Mentor FPGA流程中的集成,它提供了几个独特的功能,使每个设计人员能够更快地达到时序收敛,最大限度地减少设计变更的影响,并满足特定应用的要求。

Precision RTL是Mentor Graphics的入门级FPGA综合解决方案,可提供卓越的结果质量,是Mentor Graphics全面的FPGA供应商独立解决方案的一部分。 Precision RTL具有丰富的功能集,包括高级优化,屡获殊荣的分析和行业领先的语言支持,可实现独立于供应商的设计,加快产品上市时间,消除设计缺陷并提供卓越的结果质量。

Precision Hi-Rel,为安全关键和高可靠性应用提供基于综合的辐射效应缓解。减轻辐射效应的替代方法,例如手动将安全措施编码到设计中,可能太困难,耗时或容易出错。借助Precision Hi-Rel,设计人员可以防止单一事件影响(SEE),并从自动化,广泛的用户控制和多供应商支持中受益。

Mentor Graphics Precision 2019.1 | 1.2 Gb

Mentor, a Siemens business, is pleased to announce the availability of Precision 2019.1. This solution offers high quality of results, industry-unique features, and integration across Mentor Graphics’ FPGA Flow– the industry’s most comprehensive FPGA vendor independent solution.

Precision Synthesis

is a synthesis platform that maximizes the performance of both existing programmable logic devices (CPLDs and FPGAs) and next-generation, multi-million gate field programmable system-on-chip (FPSoC) devices. The Precision Synthesis tool provides design capture in the form of VHDL, Verilog and SystemVerilog entry, advanced register-transfer-level logic synthesis, constraint-based optimization, state-of-the-art timing analysis, schematic viewing, and encapsulated place-and-route.

FPGA Synthesis Product Suite:

-

Precision RTL Plus

is Mentor Graphics’ flagship FPGA synthesis solution offering breakthrough advantages for commercial applications and for mil-aero and safety-critical systems. Precision RTL Plus offers an improved way of designing FPGAs and increasing designer productivity. Through its advanced synthesis technologies and integration within Mentor’s FPGA flow, it provides several unique features that enable every designer to reach timing closure faster, to minimize the impact of design changes, and to address application-specific requirements.

-

Precision RTL

is Mentor Graphics’ entry-level FPGA synthesis solution offering excellent quality of results and part of Mentor Graphics’ comprehensive FPGA vendor independent solution. With a rich feature set that includes advanced optimizations, award-winning analysis, and industry-leading language support, Precision RTL enables vendor-independent design, accelerates time to market, eliminates design defects, and delivers superior quality of results.

-

Precision Hi-Rel,

provides synthesis-based radiation effects mitigation for safety-critical and high reliability applications. Alternative methods to mitigate radiation effects, such as manually coding safeguards into the design, can be either too difficult, time consuming, or error-prone. With Precision Hi-Rel, designers can protect against single-event effects (SEEs) and benefit from automation, extensive user-control, and multi-vendor support.

This tutorial video shows students how to compile a POF & SOF file which is used to program a logic design to a target FPGA device. These files are generated using the Precision Synthesis software which is part of the Mentor Graphics software package.

Mentor Graphics Corporation

is a world leader in electronic hardware and software design solutions, providing products, consulting services and award-winning support for the worlds most successful electronic, semiconductor and systems companies. Established in 1981, the company reported revenues in the last fiscal year in excess of $1.15 billion. Corporate headquarters are located at 8005 S.W. Boeckman Road, Wilsonville, Oregon 97070-7777.

Product:

Mentor Graphics Precision

Version:

2019.1.0.9

Supported Architectures:

x64

Language:

english

System Requirements:

PC / Linux *

Supported Operating Systems:

*

Size:

1.2 Gb

* System Requirements:

Supported Operating Systems

- Windows 7 SP 1 (64-bit)

- Windows 8.1 (64-bit)

- Window 10 (64-bit)

- Windows Server 2008 R2

- Windows Server 2012 & 2012 R2

Hardware:

Pentium class CPU. Pentium 3 or higher recommended.- Red Hat Enterprise Linux 6.6, 6.7, 7.0 (64-bit)

Hardware:

AMD Opteron systems with Linux Red Hat Enterprise 6.6, 7.0 (64-bit) running either KDE or GNOME window managers in shell or Next Generation GUI mode.*- SUSE Linux Enterprise (SLES) 11.0 SP3 (64-bit

Hardware:

SUSE Linux Enterprise (SLES) 11.0 running either KDE or GNOME window managers in shell or Next Generation GUI mode.*

- CentOS 6.6, 6.7, 7.0 (64-bit)

Hardware:

CentOS 6.6, 7.0 (64-bit) running either KDE or GNOME window managers in shell or Next Generation GUI mode.

* Precision Synthesis is supported for use with the Linux operating system on two hardware architectures: AMD and Inte


Mentor Graphics Precision 2019.1的图片1
Mentor Graphics Precision 2019.1的图片2
Mentor Graphics Precision 2019.1的图片3
Mentor Graphics Precision 2019.1的图片4
