一款Mac上的CAD绘图工具，为技术绘图员和设计师提供了高性能的2D CAD程序，CADintosh X 的主要特点是：交互式的绘图界面，多种功能模块，支持HPGL、DXF、PICT输入输出格式，可以用英制单位或自己定义的单位等

File size: 49 MB

CADintosh is a High Performance 2D CAD program for Technical Draftsmen and Designers. You will benefit from professional and well thought-out features for all your design requirements.

Workflow improvement and usability advantages

- Single window interface (quick access to all features without any additional tool windows)

- Retina display support

- The number of elements is only limited by your available memory

- Pre-settings are saved for each drawing

Key features: Lines and tools

- 8 pens with freely definable line widths and line colors

- 6 line types: full line, dotted line, chain line, dotted line with two dots, zigzag line, short dotted line

- Individual mode: line widths from 0.0 to 99.99 mm, and each element can be designated a different color and width (not compatible to HPGL)

- Functions available for lines, circles, dimensioning, hatching, X lines, etc.

Support for groups and layers

- 32,000 groups

- 1,024 layers

- simple layer management

Compatibility

- Import and export of DXF, HPGL, IGES and PDF

- Unicode support

- Support for symbol libraries for the import and export of symbols

- Alternative units, e.g. for inches

- Runs natively in Mac OS X

Release Notes

New features

Updated preferences dialog

Added preference to disable width check upon opening

Function for deletion of all elements outside selection

Updates features

Improved dimension DXF export with special characters

Improved pattern and material fill (display matches printing, optional factor and improved settings

More...

Supported Operation Systems:

macOS 10.8 or later 64-bit
