ESI PipelineStudio 3.5 油气仿真软件的图片1

管道套件(PipelineSuite)之一的管道工作室(

PipelineStudio

)模型,可以通过先进的仿真技术,改善天然气和液体管道的离线计划和设计仿真的效率及精确度。通过一些例如稳态和瞬态水压分析的技术,管道工作室(

PipelineStudio

)始终提供高质量的商业决策方案,用以实现更佳的财政业绩。一旦管道工作室(

PipelineStudio

)为您的管网创立了一个离线工程模型,在客户应用软件中会嵌入一个相同的模型,从而增强特殊的商业运作程序以及全面的资金性能。

灵活度

管道工作室(PipelineStudio)所具备的灵活度足以把您的管网当作一个整体考虑。PipelineStudio甚至可以同GIS及其它公共数据库和应用软件—包括其他ESI公司的产品相互整合起来。

管道工作室适用于:

1、计划编制,设备战略策划 ;

2、分析水压的特征  ;

3、设计管道及设备;

4、用于预测目的的模型;

5、来自现存数据的仿真情况。

管道工作室(PipelineStudio)可以帮助操作员在不进入控制室的情况下观察操作程序改变时所产生的反应。通过研究已制定的操作行为的模拟结果,给出高质量的决策方案,从而减少维护费用,降低维护风险。

PipelineStudio(管道工作室)开放的基础结构和普通的设计构造,使其易于同PipelineStudio(管道工作室)系列的其它产品配合使用。作为附加功能,PipelineDataExchange(管道数据交换)可以轻松地同GIS、CIS、SCADA以及其它公共数据库相互整合起来。

ESI

PipelineStudio 3.5 | 216.0 mb

PipelineStudio is the industry-leading pipeline management design software and engineering solution that combines graphical configuration and reporting tools with industry-proven simulation engines. It provides fast, accurate, robust and reliable answers to a wide range of steady-state and transient analysis challenges.

PipelineStudio delivers rapid and accurate offline Pipeline management design, planning and hydraulic analysis for natural gas and liquid pipelines through advanced state-of-the-art simulation techniques. The combination of both steady-state and transient hydraulic simulation within a feature rich Windows graphical interface enables better understanding of even the most demanding problems by providing appropriate analysis of the process. PipelineStudio has been proven to be an effective decision support tool that really can deliver financial benefit to your organization.

Its familiar Windows look and feel makes it easy to use right out of the box. Workflow enhancing techniques such as templates and complexity management along with a comprehensive set of pipes and pipeline equipment enable rapid configuration of robust and accurate models of your whole pipeline network. And once PipelineStudio has constructed an engineering model of your pipeline network, the same model can be integrated into custom applications, or other Energy Solutions products, to enhance specific business processes and your financial performance.

ESI PipelineStudio 3.5 油气仿真软件的图片2

Updates in PipelineStudio 3.5 include:

Liquid and gas pressure relief valves

- The pressure relief valve model complies with API 520 part 1, Sizing, Selection and Installation of Pressure Relieving Devices in Refineries. Currently it can model “pop” and “pilot” type valves.

- Allows modeling of any downstream pipework as well as immediate flow/pressure control downstream.

CV curve versus percent open for gas models

- CV versus percent open table has been added for better modeling of valves during open and close events on gas lines.

Updates to both gas and liquids engines

- A number of updates to the gas engine have been implemented to support the Fortran engine migration to C# engine development.

- A number of updates to DRA modeling are included, for example a significant change in the reporting of drag reduction percentage rather than drag reduction factor.

About Energy Solutions International Inc.

Headquartered in Houston Texas, Energy Solutions International (ESI) is the leading global supplier of innovative decision support software and services that enhance and integrate operational efficiency, commercial profitability and safety across pipelines as well as the energy transportation, storage, marketing and delivery functions.

Founded in 1976, ESI serves more than 500 clients working in 70 countries through its offices in the United States and around the world. ESI is committed to providing innovative, integrated solutions to address the unique challenges of our industry.

The company’s broad range of highly integrated software products and services drive greater operational efficiency and ROI through optimized design and precise, real-time control to deliver improved efficiency, transaction management, throughput management, and pipeline safety.

Our solutions integrate with each other as well as third party systems from all major SCADA Vendors including; Yokogawa, Invensys, Siemens, Honeywell, ABB, SAIC as well as major ERP systems from vendors such as SAP and JD Edwards.

Name:

ESI PipelineStudio

Version:

3.5

Home:

www.energy-solutions.com

Interface:

english

OS:

Windows XP / Vista / Seven

Size:

216.0 mb
