CG数据库 >> ANSYS Products 2020 R2 Linux

美国ANSYS公司研制的大型通用有限元分析软件最近发布了最新版本:ANSYS Products 2020 Linux SSQ版本

ANSYS Products 是融结构、流体、电磁场、声场和耦合场分析于一体的大型通用有限元分析软件。由世界上最大的有限元分析软件公司之一的美国ANSYS公司开发,它能与多数CAD软件接口,实现数据的共享和交换,如Pro/Engineer, NASTRAN,Alogor, I-DEAS, AutoCAD等, 是现代产品设计中的高级CAE工具之一。因此它可应用于以下工业领域: 航空航天、汽车工业、生物医学、桥梁、建筑、电子产品、重型机械、微机电系统、运动器械等。

软件主要包括三个部分:前处理模块,分析计算模块和后处理模块。 前处理模块提供了一个强大的实体建模及网格划分工具,用户可以方便地构造有限元模型。 分析计算模块包括结构分析(可进行线性分析、非线性分析和高度非线性分析)、流体动力学分析、电磁场分析、声场分析、压电分析以及多物理场的耦合分析,可模拟多种物理介质的相互作用,具有灵敏度分析及优化分析能力。 后处理模块可将计算结果以彩色等值线显示、梯度显示、矢量显示、粒子流迹显示、立体切片显示、透明及半透明显示(可看到结构内部)等图形方式显示出来,也可将计算结果以图表、曲线形式显示或输出。 软件提供了100种以上的单元类型,用来模拟工程中的各种结构和材料。该软件有多种不同版本,可以运行在从个人机到大型机的多种计算机设备上,如PC,SGI,HP,SUN,DEC,IBM,CRAY等。

ANSYS Products 2020  Linux | 21.6 Gb

The Ansys product team is pleased to announce the availability of Ansys Products 2020 R1, is offers a comprehensive software suite that spans the entire range of physics, providing access to virtually any field of engineering simulation that a design process requires.

ANSYS offers a comprehensive software suite

that spans the entire range of physics, providing access to virtually any field of engineering simulation that a design process requires. Organizations around the world trust ANSYS to deliver the best value for their engineering simulation software investment.

Simulation-driven product development takes engineering simulation to another level ― the unequalled depth and breadth of our software coupled with its unmatched engineered scalability, comprehensive multiphysics foundation and adaptive architecture set our technology apart from other CAE tools. These ANSYS advantages add value to the engineering design process by delivering efficiency, driving innovation and reducing physical constraints enabling simulated tests that might not be possible otherwise.

Before every breakthrough in autonomous driving, robotics, 3D printing, reusable rocket engines, digital twins, patient-specific healthcare interventions and advanced fighter jets, there’s an engineer, designer, entrepreneur, scientist or visionary using ANSYS simulation solutions to ensure a successful outcome. Watch this video to learn how ANSYS Pervasive Engineering Simulations can turn your dream product into a reality.

ANSYS Inc. Founded in 1970,

ANSYS employs nearly 3,000 professionals, many of whom are expert M.S. and Ph.D.-level engineers in finite element analysis, computational fluid dynamics, electronics, semiconductors, embedded software and design optimization. Our exceptional staff is passionate about pushing the limits of world-class simulation technology so our customers can turn their design concepts into successful, innovative products faster and at lower cost. As a measure of our success in attaining these goals, ANSYS has been recognized as one of the world's most innovative companies by prestigious publications such as Bloomberg Businessweek and FORTUNE magazines.


ANSYS Products


2020 R1 (

Supported Architectures:




System Requirements:



21.6 Gb

* System Requirements:

ANSYS Products 2020 R2 Supported Platforms

- Red Hat Enterprise Linux (RHEL) 7.4, 7.5, 7.6, and 7.7 (64-bit)

- SUSE Enterprise Linux Server & Desktop (SLES/SLED) 12 SP3 and SP4 (64-bit)

- SLES/SLED 15 SP1(64-bit)

- Community Enterprise OS (CentOS)7.4, 7.5, 7.6, and 7.7(64-bit

Additional Hardware and Software Requirements

- Intel 64 / AMD64 system with the correct operating system version installed

- 8 GB of RAM (Minimum)

- 128 GB free on the hard drive is recommended

Minimum Graphics Requirements

ANSYS Products, Linux Platfoms:

Discrete graphics card with the latest drivers and compatible with the supported operating systems. For full functionality, use of a recent NVIDIA Quadro or AMD Radeon Pro card with at least 1 GB of discrete video memory and supporting, at a minimum, OpenGL version 4.5

ANSYS Discovery Live:

NVIDIA Discrete graphics card (Quadro recommended) with the latest drivers. Kepler-, Maxwell-, Pascal-, Volta, or Turing-based cards are recommended (Maxwell 2000 or better). At least 4 GB of discrete video memory (8 GB recommended). OpenGL version 4.5 or above.


Some ANSYS products support problem solving on the graphics processor (GPGPU capability). The additional graphics card requirements for GPGPU are included in the GPU Accelerator Capibilities document at> Support> Platform Support

In addition, ANSYS 2020 R2 supports the following Virtual Desktop Infrastructure:

- NICE DCV 2020.0 (Red Hat 7, SLES 12, CentOS 7) with VMware vSphere ESXI 6.5 U2 or Citrix Hypervisor 8.0 GPU Pass-Through only

ANSYS 2020 R2 Supported Platforms Compilers

To take advantage of improving compiler technologies, ANSYS updates supported compilers from time to time. The following compilers are supported for user-programmable features and functions at ANSYS 2020 R2:

- GCC 6.3 (Linux)

- Intel Parallel Studio XE 2019, Update 3 (Linux)

ANSYS Products 2020 R2 Linux的图片1
ANSYS Products 2020 R2 Linux的图片2

发布日期: 2020-07-13
