CG数据库 >> Altair HyperWorks v12.0.1 X64 CAE平台

Altair HyperWorks v12.0.1 X64 CAE平台的图片1Altair宣布正式发布HyperWorks 12.0——PLM市场上最全面的计算机辅助工程CAE平台。

HyperWorks

12.0在产品优化、有限元建模、多物理场分析、动力总成耐久性分析、轻量化设计以及其它方面带来新的功能,促进最终用户生产力水平的提升。

“HyperWorks12.0提供自动化及易用的功能,从而节省时间、保证精度并达到轻量化;还提供更多探索不同设计的机会。” Altair首席技术官James Brancheau说,“HyperWorks平台极具开放性,同时各个模块间的紧密整合、协同工作,使工程师、设计师和分析师可以自信地创建并评估他们产品的各方面性能,这种自信源于他们可以设计出满足要求的最优产品。”

HyperWorks 12.0主要在以下方面得到提升和加强:

实用性 –– 旨在压缩时间和提供易用的CAE技术,包括改进模型浏览器,新的简化用户界面用于快速建模(BasicFEA)和对3D可视化的支持(HyperView)。

先进的网格划分算法–– 多种对壳和体网格划分的功能,比如中面网格划分并自动从复杂的CAD几何映射厚度及附带的质量控制机制(HyperMesh)。

模型装配 –– 多种复杂的模型装配方法用于快速装配复杂的模型,包括自动化的焊点生成方法。

接口––加强CAD导入和导出的互用性,复合材料接口以及协同仿真数据管理。

动力总成耐久性和大规模NVH分析和优化 –– 新增和加强的功能包括一步法传递路径分析(TPA)和多级子结构求解器OptiStruct(AMSES)。

显式和隐式有限元分析增加一些新的材料准则和失效模式以提高精度(RADIOSS)。

GPU支持 –– RADIOSS中的隐式求解器、OptiStruct和AcuSolve增加对GPU的支持,通过“节省成本”的软件授权模式管理。

Altair HyperWorks v12.0.1 X64 CAE平台的图片2

自动扩展–– 允许与第三方组件实现联合多体动力学仿真分析(MotionSolve)。

最顶级的优化能力–– 加速轻量化设计并且包含新的复合材料制造约束(OptiStruct)。

噪音预测分析 –– 新的Ffowcs-Williams-Hawkings噪声求解器精确地预测远处麦克风位置的噪音水平(AcuSolve)。

智能多物理场分析–– 新颖的统一的软件授权模式为用户带来高性价比的HyperWorks及Altair合作伙伴联盟(Altair Partner Alliance)中的求解器,用于分析复杂的多物理场问题。

设计探索、研究和优化 ––全新设计发布的HyperStudy加速设计稳健性和可靠性研究。

仿真驱动概念设计工具–– 最新版的solidThinking Inspire允许设计师在设计流程的早期阶段创建并探索有效结构设计的概念,同时solidThinking Evolve带来基于NURBS的3D建模和渲染环境以创建可制造的模型以及使用卓越的视觉效果渲染CAE结果。

HyperWorks12.0的功能提升得到了测试用户的肯定。比如,波音公司的技术研究员Jonathan Gabrys说:“新的3D能力创建了一个身临其境的环境,提升了我们概念设计和分析的能力。尤其是,能够解读复杂的分析结果,比如应力场或位移,以及使用3D可视化提供深层次的理解。”

除了HyperWorks,Altair还通过Altair合作伙伴联盟(APA)提供第三方技术和无以伦比的价值。通过直接使用HyperWorks Units(HWUs)系统,HyperWorks客户可以使用来自近30家战略合作伙伴所开发的大量专业软件。

随着HyperWorks12.0的发布,Altair继续增加HyperWorks软件授权模式的价值、灵活性和移动性。同时可以通过HyperWorks On-Demand(HWOD)在“云端”使用,HWOD是使用Altair PBS Works为高性能计算(HPC)做作业负载管理、作业提交、监视和工作量分析而创建的平台。它可以实现轻松访问云计算以及随后的统计信息——所有这些功能均可以采用现有的HWUs,也就意味着所需要的额外投资最小。

更多关于HyperWorks 12.0的信息,请访问:

http://www.altairhyperworks.com.cn/hw12

.

Altair HyperWorks v12.0.1 X64 CAE平台的图片3

关于Altair

Altair通过优化分析、管理和可视化商务及工程信息帮助客户创新及决策。Altair是一家私人公司,拥有超过1800员工,分公司遍布北美、南美、欧洲和亚太地区。Altair拥有27年做高端工程和计算软件、企业分析解决方案和创新产品设计和开发的经验,持续在各个行业为客户提供竞争优势。更多信息,请访问www.altair.com.cn或www.simulatetoinnovate.com

Altair HyperWorks (64bit) 12.0.1 | 5.3 Gb

Altair HyperWorks 12.0 is one of the most comprehensive tools open architecture FE modeling

Continuing the tradition of increasing the number of merit HyperWorks with each release, the HyperWorks 12.0 further developed software: AcuSolve 12.0 and solidThinking 9.0

AcuSolve-package for the calculation of hydrodynamic problems (CFD) and multidisciplinary zadach.Blagodarya AcuSolve appearance, the capacity of the solver HyperWorks, allowing designers and engineers of all skill levels an opportunity to solve the problems of gas and fluid dynamics. AcuSolve allows engineers to solve the most time-consuming and complex task, in particular, the problem of unsteady flow and the interaction of liquid and solid structures and to obtain reliable results.

solidThinking-pack for 3D modeling and visualization. These additions increase the already impressive suite of modeling platform HyperWorks. Further expansion of HyperWorks will occur due to a growing list of partner solutions HyperWorks. Partner solutions available to customers HyperWorks, licensed HyperWorks.

FE solver RADIOSS to HyperWorks 12.0 can perform new types of analysis, including the determination of the spectral density of complex eigenvalues ​​and mode shapes for pre-loading, as well as to material and geometric non-linear implicit analysis. RADIOSS provides breakthrough performance with advanced technology, which increases the speed and accuracy of detailed explicit modeling.

HyperWorks 12.0 modernize FE modeling and visualization capabilities union HyperMesh and HyperView in one solution. In addition, significant improvements have helped to create the appearance of an even easier to use interface.

In HyperWorks 12.0, HyperMesh in expanded opportunities for creating a grid for acoustic problems, the opportunity to visualize the three-dimensional shell and beam models.

Also in the HyperWorks now includes new collaboration tools that provide the ability to work outside the organization. These updates are tightly integrated with applications HyperWorks, provides an intuitive experience to manage personal and shared data and processes without leaving the familiar environment HyperWorks.

Hundreds of other improvements and enhancements make the most versatile version 12.0 release of HyperWorks to date. A complete list of new features, improvements and enhancements HyperWorks 12.0 can be found at HyperWorks.

Modules:

HyperMesh

- The module organization of input data, splitting patterns, use of materials itp

Performs fast and efficient decomposition of the original model.

Can be run in different "environments" for different solvers.

HyperCrash

- The module is calculating the dynamic impact and collisions.

OptiStruct and RADIOSS

- Solvers of structural and non-linear problems. May be running out of a shell or separately.

HyperView and HyperView Player

- The module visualization and postprocessing.

HyperStudy and HyperStudy DSS

- The module performance optimization and multivariate analysis.

HyperGraph and HyperGraph 3D

- Postprocessors with great potential.

MotionView and MotionSolve

- Viewer and solver for problems of kinematics and dynamics.

Fully compatible (directly or inversely) with MSC.ADAMS, ADM is able to cheat and ACF files from ADAMS!

BatchMesher

- Avtorazbienie and support assemblies. Written in Java

Name:

Altair HyperWorks

Version:

(64bit) 12.0.1

Home:

www.altairhyperworks.com

Interface:

english

OS:

Windows XP / Vista / Seven

Size:

5.3 Gb

Altair HyperWorks v12.0.1 X64

发布日期: 2013-09-26
