CG数据库 >> 《SolidCAM 2011 SP5破解版32/64位》SolidCAM 2011 SP5 for SolidWorks 2009-2012 32bit &am

SolidCAM除了秉承了一贯的功能强大,易学易用的特点外,新功能的增加也是SolidCAM的一大亮点,其中车铣复合与铣车复合功能的应用细分、车/铣复合机床仿真、HSS高速曲面加工、叶轮五轴加工专项模块、三坐标检测自动编程软件CMM,所有这些功能的增加都将极大提高使用者的行业竞争力。

SolidCAM®是一套SolidWorks®的先进计算机辅助制造工具。在SolidWorks同一操作环境下,免除档案转换引起数据的遗失、时间的延误,进行计算机辅助加工,过程更快捷方便。

SolidCAM提供2.5轴铣削,3轴铣削,3+2多边加工,5轴联动加工,车削+驱动工具,2/4轴电火花加工(2/4)轴电火花加工(2/4轴线削)。SolidCAM系统优点包括:

● 速切削支援任何CNC控制器。

● 曲面或实体不需转换就可直接做2D或3D加工设定。

● 开创性的加工范本,可保存宝贵的加工技术与流程,只要修改加工图形即可快速产生所需的加工程式。

● 自动侦知残料,自动清角,3D棱线自动沿面加工,支援二次加工。

● 加工设定后,可快速计算产生NC程式,刀具可自动重新编号。

● 提供2D/3D刀具路径模拟,CAD图形模拟,素材模拟,实体模拟,残料显示,车床内/外径切削等多样的模拟,可显示数值并计算加工时间。

● 智慧型巡弋加工法:加工过程可全程无提刀,减少提刀再下刀的表面不良度。

● 支援G2/G3圆弧切削:一般机床也可快出平滑的曲面。

● 可纵向及横向来回做切槽,内/外径,轮廓,深槽,切断,端面切槽,车牙切削,过程一气呵成,无停滞期。

● 弹性的NURBS曲面,可与实体作几何运算,无相连的曲面可自动修补成单一曲面。

● 随时记录图形,即使突然断电也能保存最终设计图形 。

2D铣床

->袋状加工

->轮廓加工

->开槽加工

->智能识别SolidWorks孔特征

● 支援所有钻孔循环

● 可依选取顺序/方向/距离自动排列最佳钻空顺序

3D铣床

->粗加工

● 可在指定的Z深度内执行等高切削

● 支援G2/G3圆滑化切削,可依指定的容许误差将刀具路径圆滑化

● 智慧型辅间作业:可自动侦知进刀深度之间未被切削的平面或边线,并自动以轮廓方式来切削此范围

->中粗加工

->精加工

● 等高切削    ● 曲面切削    ● 底面切削

● 直线切削    ● 辅正切削    ● 彷削切削

● 棱线切削   ● 螺旋切削

->切削模拟

● 多样化的模拟,可分别显示2D/3D刀具路径,加工后残料,CAD图形模拟,素材模拟,实体切削模拟

● 可控制模拟速度及单节,连续,快速模拟,可欲设停止点及显示加工数值并计算时间

● 模拟时可自由旋转,缩放,设定模拟视图

其特点在于它能够与SolidWorks的无缝集成,可在单一窗口内操作,而且与SolidWorks的设计流程互相关联。事实上,这个软件在工业产品制造、气车、航空工业、电子、模版工作及於快连制作样版时均被广泛使用。

SolidCAM 2011 SP5 for SolidWorks 2009-2012 32bit & 64bit

Languages: Chinese Simplified, Chinese Traditional, Czech, Danish, English, French, German, Hebrew, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Spanish, Turkish

SolidCAM is the complete, ‘best-in-class’ Manufacturing Suite for efficient and profitable CNC-Programming inside SolidWorks and provides seamless single-window integration and full associativity with the SolidWorks design model.

About SolidCAM Ltd.

Who is SolidCAM and why can they do what other CAM suppliers can’t?

Founded 1984

With over 27 years expertise in CAM development and applications, SolidCAM started out as a fully integrated CAD/CAM system. After many years of successful development, the founder, Dr. Emil Somekh, realized it was more efficient to focus on developing an integrated CAM system for SolidWorks and thus leverage all the power of the company to develop the CAM functionality and use the great import and CAD power of SolidWorks. This same architecture was used to later integrate with Inventor also.

To provide a powerful, easy-to-use, complete, integrated CAD/CAM solution that allows manufacturers to leverage what they already have, for improved efficiency and profits and prepare them for higher level machining.

Our challenge - To overcome the CAM Legacy of Broken Promises by other CAM suppliers:

- Associativity claims - from stand alone CAM products!

- Automagic tool paths – that work only on simple parts!

- Miracle tool paths that only work on high-end machines, with expensive tools and holders!

Some of the major Benefits of using SolidCAM:

- Associativity:

Tool paths Update when Part changes

Use feature Tree for picking features

- Scalable with packages for all CNC machine types and Applications

Featuring:

Powerful and mature simultaneous 5 axes

Advanced Mill-turn up to 7 axes

- SolidWorks Look and Feel - Single Window interface

- iMachining

- Automatic feature recognition for locating and selecting Holes and Pockets

- HSM - High Speed machining for optimized Tool Paths

- HSS - High Speed Surface machining for Undercuts and Single surface constraint.

- Templates and presets for repeated parts and novice users

- 100’s of SolidCAM Professor 24-7, 365 Right on Website, no Login needed

- Rest material to eliminate air cuts and speed up smaller-tool clean-ups

- SolidCAM 10 years as SolidWorks gold partner

- Real-time life-like simulations -

Solid Verification with Gouge and Holder checking

Full Machine Simulations with Gouge and Holder checking

- Works in the SolidWorks assembly modeler to use Fixtures, Tooling and Vices in simulations

- Open Post processor with Post editing Tools
